FBE Lining and Coating Steel Pipe

FBE coating steel pipe

--- FBE is a high performance anti-corrosion coating that provides excellent protection for small and large diameter pipelines with moderate operating temperatures.

FBE coating seamless steel pipe, FBE coating welded steel pipe, FBE coating spiral welded steel pipe, FBE coating LSAW steel pipe

FBE material: The epoxy powder shall consist of a one-component, fusion-bonded material comprised of epoxy resin, curing agents, catalysts, fillers, colorants, flow-control agents, and ultraviolet-light-resistance agents that, when applied to the preheated substrate, will uniformly coalesce and cure to produce a homogeneous film that complies with the requirements.

Main standard of FBE coating steel pipe

AWWA C213 standard for Fusion-bonded epoxy coating for the interior and exterior of steel water pipelines

Specification of FBE coating steel pipe

Pipe diameter: 90mm to 1220mm
Pipe wall thickness: 2mm to 60mm
Pipe length range: 5.5meters to 14meters
Min Recommended Handling and Construction Temperature: 30℃
Max Recommended Operating Temperature: 110℃

Application of FBE coating steel pipe

FBE coating that has been abrasive blast cleaned and inspected shall be heated to a temperature in accordance with coating powder our data sheet. Fluid bed magnets shall be inspected and cleaned prior to startup. Coating shall be applied to the specified thickness in one pass through the coating booth.

FAQ of FBE coating steel pipe

Q: Do you have coating of other types?

A: Yes. There are different coating types.

     Anti-rusted coating: varnish painting, black painting or other color painting.

     Anti-corrosion coating: 3LPE, 3LPP, Liquid epoxy and other anti-corrosion coating.

Q: How to pack coated steel pipe in your company?

A: Usually, cotton ropes are wrapped around both ends of steel pipes for protection. And pipe ends are covered by plastic caps or metal protectors.

Besides, non-woven bags can be used for packing surface of each pipes. And if clients want to pack steel pipes by wooden cases, it can be arranged by us.

Q: What is maximum length of coated steel pipe?

A: The maximum length is 14meters. Coated steel pipes of 12meters can be loaded into 40ft containers.

Longer than 12meters steel pipes is suit for transporting by bulk vessel.
